Installing the Interface Module Carrier
It is recommended that you always install the IM carrier (A9XX-2IMA-CARRIER) in the lower slot before
installing the carrier in the upper slot.
Note
Procedure
Step 1 Before inserting an IM carrier, make sure that the chassis is grounded.
Step 2 To insert the IM carrier, carefully align the edges of the IM carrier between the upper and lower edges of the
router slot.
Step 3 Carefully slide the IM carrier into the router slot until the IM carrier makes contact with the backplane. See
the figure below.
Figure 50: Installing the IM Carrier
Interface Module Installation
The following sections describe the various tasks of associated with interface module installation on the Cisco
ASR 907 Router:
Cisco ASR 907 Router Hardware Installation Guide
78
Installing the Cisco ASR 907 Router
Installing the Interface Module Carrier
