The other single USB 2.0 Type-A receptacle is provided on the RSP front panel for inserting external USB
mass storage devices such as standard USB flash drives. It is used to load images, store configurations, write
logs, etc. It supports operation up to 12Mbps
The table below summarizes the USB console port pinout.
DescriptionDirectionSignal NamePin
+5VDC (500mA)VccA1
Data -D-A2
Data +D+A3
GroundGndA4
The USB Console port +5VDC is input and operates as an USB peripheral device.
Note
USB Flash/MEM Port Pinout
The table below summarizes the USB flash/MEM port pinout.
Table 32: Single USB Flash/MEM Port
DescriptionDirectionSignal
Name
Pin
+5VDC
(500mA)
VccA1
Data -D-A2
Data +D+A3
GroundGndA4
USB TYPE-A receptacle used.
Note
The USB flash/MEM port +5VDC is output. We provide power for USB flash/MEM, and it operates as a
USB host device.
Note
Fiber-Optic Specifications
The specification for optical fiber transmission defines two types of fiber: single-mode and multimode. Within
the single-mode category, three transmission types are defined: short reach, intermediate reach, and long
