UnshieldedShielded
—6Transmit Shield6
—7Not Used7
—8Not Used8
Management Ethernet Port Pinout
A single management copper ENET port supporting 10/100/1000Base-T operation exists on each RSP. There
is no direct access to the CPU of the other RSP. It uses a standard RJ45 jack.
This is not a data plane port.
Note
The table below summarizes the Management Ethernet port pinout.
Table 31: Management Ethernet Port Pinout
DescriptionSignal
Name
Pin
TRP0+1
TRP0-2
TRP1+3
TRP1-4
TRP2+5
TRP2-6
TRP3+7
TRP3-8
USB Console Port Pinout
Two individual Type-A USB connector are used for USB console and USB mass storage. One single USB
2.0 Type-A receptacle is provided on the RSP front panel for providing console access to ROMMON, IOS-XE
and diagnostics. It operates as a USB peripheral only for connection to an external host PC. This requires the
use of a Type-A to Type-A connector instead of a standard USB cable.
The use of the USB console is mutually exclusive with the RS232 console/Aux port. While a USB cable is
inserted, access is automatically switched to this port.
Note
Cisco ASR 907 Router Hardware Installation Guide
179
Troubleshooting
Management Ethernet Port Pinout
