Cisco ASR 907 User Manual

Signal Name
Connector (32-47)
Signal Name
Connector (16-31)
Signal Name
Connector (0-15)
Pin
TX_PORT37_TIPTX_PORT21_TIPTX_PORT5_TIP24
TX_PORT36_RINGTX_PORT20_RINGTX_PORT4_RING25
TX_PORT36_TIPTX_PORT20_TIPTX_PORT4_TIP26
TX_PORT35_RINGTX_PORT19_RINGTX_PORT3_RING27
TX_PORT35_TIPTX_PORT19_TIPTX_PORT3_TIP28
TX_PORT34_RINGTX_PORT18_RINGTX_PORT2_RING29
TX_PORT34_TIPTX_PORT18_TIPTX_PORT2_TIP30
TX_PORT33_RINGTX_PORT17_RINGTX_PORT1_RING31
TX_PORT33_TIPTX_PORT17_TIPTX_PORT1_TIP32
TX_PORT32_RINGTX_PORT16_RINGTX_PORT0_RING33
TX_PORT32_TIPTX_PORT16_TIPTX_PORT0_TIP34
RX_PORT47_RINGRX_PORT31_RINGRX_PORT15_RING35
RX_PORT47_TIPRX_PORT31_TIPRX_PORT15_TIP36
RX_PORT46_RINGRX_PORT30_RINGRX_PORT14_RING37
RX_PORT46_TIPRX_PORT30_TIPRX_PORT14_TIP38
RX_PORT45_RINGRX_PORT29_RINGRX_PORT13_RING39
RX_PORT45_TIPRX_PORT29_TIPRX_PORT13_TIP40
RX_PORT44_RINGRX_PORT28_RINGRX_PORT12_RING41
RX_PORT44_TIPRX_PORT28_TIPRX_PORT12_TIP42
RX_PORT43_RINGRX_PORT27_RINGRX_PORT11_RING43
RX_PORT43_TIPRX_PORT27_TIPRX_PORT11_TIP44
RX_PORT42_RINGRX_PORT26_RINGRX_PORT10_RING45
RX_PORT42_TIPRX_PORT26_TIPRX_PORT10_TIP46
RX_PORT41_RINGRX_PORT25_RINGRX_PORT9_RING47
RX_PORT41_TIPRX_PORT25_TIPRX_PORT9_TIP48
RX_PORT40_RINGRX_PORT24_RINGRX_PORT41_TIP49
RX_PORT40_TIPRX_PORT24_TIPRX_PORT8_TIP50
Cisco ASR 907 Router Hardware Installation Guide
172
Troubleshooting
Patch Panel Pinout
