6. Connect the USB cable to the PC and the switch console port. The USB console port LED turns green,
and the Found New Hardware Wizard appears. Follow the instructions to complete the driver installation.
DETAILED STEPS
Step 1 Obtain the Cisco USB console driver file from the Cisco.com web site and unzip it.
You can download the driver file from the Cisco.com site for downloading the switch software.
Note
Step 2 If using 32-bit Windows XP, double-click the setup.exe file in the Windows_32 folder. If using 64-bit Windows XP,
double-click the setup(x64).exe file in the Windows_64 folder.
Step 3 The Cisco Virtual Com InstallShield Wizard begins.
Step 4 The Ready to Install the Program window appears. Click Install.
Step 5 The InstallShield Wizard Completed window appears. Click Finish.
Step 6 Connect the USB cable to the PC and the switch console port. The USB console port LED turns green, and the Found
New Hardware Wizard appears. Follow the instructions to complete the driver installation.
Installing the Cisco Microsoft Windows 2000 USB Driver
SUMMARY STEPS
1. Obtain the Cisco USB console driver file from the Cisco.com web site and unzip it.
2. Double-click the setup.exe file.
3. The Cisco Virtual Com InstallShield Wizard begins. Click Next.
4. The Ready to Install the Program window appears. Click Install.
5. The InstallShield Wizard Completed window appears. Click Finish.
6. Connect the USB cable to the PC and the switch console port. The USB console port LED turns green,
and the Found New Hardware Wizard appears. Follow the instructions to complete the driver installation.
DETAILED STEPS
Step 1 Obtain the Cisco USB console driver file from the Cisco.com web site and unzip it.
You can download the driver file from the Cisco.com site for downloading the switch software.
Note
Step 2 Double-click the setup.exe file.
Step 3 The Cisco Virtual Com InstallShield Wizard begins. Click Next.
Step 4 The Ready to Install the Program window appears. Click Install.
Step 5 The InstallShield Wizard Completed window appears. Click Finish.
Step 6 Connect the USB cable to the PC and the switch console port. The USB console port LED turns green, and the Found
New Hardware Wizard appears. Follow the instructions to complete the driver installation.
Cisco Catalyst 2960-L Series 8-Port and 16-Port Switch Hardware Installation Guide
64
Configuring the Switch
Installing the Cisco Microsoft Windows 2000 USB Driver

Cisco Catalyst 2960-L Series Specifications

General

Series	Catalyst 2960-L
Ports	8, 16, 24, or 48 Gigabit Ethernet ports
Layer	Layer 2
Flash Memory	64 MB
MAC Address Table Size	8, 000 entries
Uplink	2 or 4 Gigabit SFP
PoE	Available on selected models
VLAN Support	Up to 255 VLANs
Power Supply	Internal power supply
Operating Temperature	0°C to 40°C (32°F to 104°F)
Dimensions	44.5 x 27.9 x 4.45 cm (17.5 x 11.0 x 1.75 in.)
