Figure 31: Securing the Power Cord in the Retainer
Installing the Cable Guard (Optional)
The cable guard prevents tampering with the cables after the cables are installed. The cable guard
(CMPCT-CBLE-GRD=) is not included with the switch, but you can order it from your Cisco representative.
You can use the cable guard when the switch is mounted on a desk, under a desk, or on a wall.
Note
The cable guard is shipped with these items:
• Two 0.5 in. (12.7 mm) number-8 Phillips wood screws
• Two number-10 Phillips pan-head screws
• Two washers
Step 1 (Optional) Attach the supplied washers before you install the cable guard.
This is only required if you are not installing the wall-mount brackets.
Note
Figure 32: Using the Washer
Washer1
Cisco Catalyst 2960-L Series 8-Port and 16-Port Switch Hardware Installation Guide
35
Switch Installation
Installing the Cable Guard (Optional)
