Figure 29: Locking the Retainer
Latches3AC power cord1
Smaller sleeve for thin power
cords
2
Step 5 (Optional) Use the small sleeve for thin power cords. Use the small sleeve to provide greater stability for thin cords.
Detach the sleeve, and slide it over the power cord.
Figure 30: Sleeve Around the Power Cord
AC power cord2Smaller sleeve for thin power
cords
1
Step 6 Secure the AC power cord by pressing on the retainer.
Cisco Catalyst 2960-L Series 8-Port and 16-Port Switch Hardware Installation Guide
34
Switch Installation
Installing the Power Cord Retainer (Optional)
