Figure 27: Inserting the Retainer through the Lanced Loop
Sleeve for thinner power
cords
3AC power cord1
Loop4Power cord retainer2
Step 3 Slide the retainer through the first latch.
Figure 28: Sliding the Retainer Through the Latch
Latch3AC power cord1
Smaller sleeve for thin power
cords
2
Step 4 Slide the retainer through the other latches to lock it.
Cisco Catalyst 2960-L Series 8-Port and 16-Port Switch Hardware Installation Guide
33
Switch Installation
Installing the Power Cord Retainer (Optional)
