Cisco CVR100W Administration Guide

Introduction
Getting to Know the CVR100W
Cisco CVR100W Wireless-N VPN Router Administration Guide 11
1
LAN (1-4) The numbered lights correspond to the LAN ports on the back
panel of the CVR100W.
• Solid blue when the CVR100W is connected to a device
through the corresponding LAN port (1, 2, 3, or 4).
• Flashes blue when the CVR100W is sending or receiving
data over that LAN port.
• Off when the LAN port has no connection.
WPS • Solid blue when the WPS connection is configured.
• Flashes blue once per second when the WPS progress
is experiencing problems.
• Off when the WPS connection is configured or there is
no WPS connection.
Wireless • Solid blue when the wireless module is enabled with
100% Wi-Fi power.
• Solid amber when the wireless module is enabled with
50% Wi-Fi power.
• Flashes blue when the CVR100W is sending or receiving
data on the wireless module.
• Off when the wireless module is disabled.
WAN • Solid blue when the CVR100W is connected to the
Internet through your cable or DSL modem.
• Flashes blue when the CVR100W is sending or receiving
data through the WAN port.
• Off when the WAN port has no connection.
POWER • Solid blue when the CVR100W is powered on and is
operating normally.
• Flashes blue when the system is booting or the system
is upgrading the firmware.
• Off when the CVR100W is powered off.

Cisco CVR100W Specifications

General

Brand	Cisco
Model	CVR100W
Category	Network Router
Language	English
