Cisco CVR100W Administration Guide

Configuring Network
Configuring LAN Settings
Cisco CVR100W Wireless-N VPN Router Administration Guide 45
3
STEP 5 If you select DHCP Relay, enter the address of the relay gateway in the Remote
DHCP Server field. The relay gateway transmits DHCP messages between
multiple subnets.
STEP 6 Click Save.
Configuring VLAN
A Virtual LAN (VLAN) is a group of endpoints in a network that are associated by
function or other shared characteristics. Unlike LANs, which are usually
geographically based, VLANs can group endpoints without regard to the physical
location of the equipment or users.
To c r e a t e a V L A N :
STEP 1 Choose Networking > LAN > VLAN Configuration.
STEP 2 Click Add Row.
STEP 3 Enter the following information:
Starting IP Address Enter the first address in the IP address pool. Any new
DHCP client joining the LAN is assigned an IP address
in this range (the ending IP address in the pool is
determined by the value that you enter in the
Maximum Number of DHCP Users field).
Maximum Number of
DHCP Users
Enter the maximum number of DHCP clients.
IP Address Range (Read-only) Displays the range of IP addresses
available to the DHCP clients.
Client Lease time Enter the duration (in hours) for which IP addresses are
leased to clients.
Static DNS 1 Enter the IP address of the primary DNS server.
Static DNS 2 Enter the IP address of the secondary DNS server.
Static DNS 3 Enter the IP address of the tertiary DNS server.
WINS Enter the IP address of the primary WINS server.
