Cisco D9854-I User Manual

Setup Menu
121
Menu Item
Description
Parameters
Config Type
Indicates the current DPM
configuration change by a user
after changing the Output
Mode.
Edited by User - DPM changes were made.
Unmodified - No changes were made after setting a new
Output Mode.
Auto Re-Mapped - Output map changed automatically to
fix the output channel or PID conflicts at the time of setup.
Changed by Uplink - DPM output changes were initiated
by an encoder.
Descramble Mode
This parameter selects whether
the receiver should scramble
the output even if it is
authorized to receive the
channel.
The default mode is Descrambled.
Scrambled - Scrambles the output channel even if the PE is
authorized and can descramble the channel.
Descrambled - Descrambles the output channel, and passes
in-the-clear channels.
Insert Null Packet
This parameter selects whether
to insert null packets in the
output stream.
Null packets are always
inserted if the Rate Control is
set to User.
Yes or No
FEC Scheme
Select the FEC packet sending
arrangement. They are defined
in the pro-MPEG FEC and the
SMPTE FEC standards.
If the FEC for a specific MOIP
Stream is set to None, all FEC-
related settings for that stream
are ignored.
For more information, see
MOIP Stream (see "MOIP
Streams" on page 122).
Non-Block Aligned - Each FEC packet receives L packets
after the last related data packet.
Block Aligned - Column FEC packets are sent by using an
interleaver.
Note: For more information, refer to SMPTE 2002-1-2007.
Auto Map
Sets whether the DPM resolves
the channel and PID collisions
automatically on the transport
outputs. New values are
assigned to the parameters that
caused the conflict. The new
assigned values are not used by
any incoming transport or other
PE outputs. If a collision is
detected, you can review the
new changes before applying
the new changes.
Yes or No
