Configuring Transport Stream Information
4 Click the radio button of the program entry you want to edit.
5 Click Edit. The DPM PE PID MAP dialog box opens.
6 Enter the Output Channel # you want to map to the input channel (Input
Channel #). This value is only used if the PE Action was set to Map. You can
enter a range from 1 to 65535.
7 Enter the Output PMT PID you want to map to the Input PMT PID.
8 In the PE PID MAP area, you can select an existing PID mapping entry you want
to modify or click Add Row to create a new entry.
9 The Input Stream indicates the input service that will be mapped by the current
entry. The Input PID displays the input PID (1 to 8190) that will be mapped by
the current entry. This is only used if the Action is set to Map.
10 From the Action drop-down list, choose the action to perform on the current
PID. The Drop action is always performed, but the Map option is only applied if
the PE Action is Map and the Remapping Mode is Svc ID & PID in the DPM
General Settings section.
The service selected by the Category and Instance will be mapped
to the specified PID. This is only applied if the PE action is Map
and the Remapping Mode is Svc ID & PID.
The service selected by the Category and Instance will be removed
from the PMT and the output stream.
11 In the Stream Type field, enter a stream type to map within a PE to a specified
PID (0 to 255).
