Chapter 4 Front Panel Operation
66
MOIP In Redundancy Status
Note: This feature is for D9854-I only.
Menu Item
Description
Parameters
Port In Use
The current input port in use.
Data1 or Data2
Change Reason
Description of the reason for the last redundancy
status change.
None, Setup,
EthLinkStatus, TS
Status, ProgStatus
Change Date &
Time
Displays the last date and time the redundancy
status changed.
YYYY/MM/DD
HH:MM:SS
MOIP In IP Source Status
Note: This is for D9854-I only.
Menu Item
Description
Parameters
Data1/Data2
Source Host
When locked, this displays the source/host IP
address of the originator. If the signal is not locked,
it will display N/A.
–
Data1/Data2 MOIP
Type
Displays the encapsulation type of transport
stream received from the DATA1 or DATA2 port.
UDP or RTP
MOIP In FEC Status
Note: This is for D9854-I only.
Menu Item
Description
Parameters
FEC Rate
Displays the input stream bit rate, reported by the
FEC decoder.
in Mbps
CEC
Indicates the current Corrected Error Count for the
received signal.
–
PER
Indicates the current Packet Error Rate of the
received signal.
–
FEC Rows(D)
Displays the number of FEC rows.
0 to 20
Present
Displays whether the FEC rows stream is present.
Yes or No
Col(L)
Displays the number of FEC columns
0 to 20
Present
Displays whether the FEC columns stream is
present.
Yes or No
FEC Overhead
Displays the FEC overhead, compared to the
transport stream bit rate, in percentage.
–
