Cisco IE-3000-8TC Hardware Installation Guide

2-26
Cisco IE 3000 Switch Hardware Installation Guide
OL-13017-01
Chapter 2 Switch Installation
Installing the Switch
Step 4 Push the DIN rail latches in after the switch is over the DIN rail. See Figure 2-21.
Figure 2-21 Pushing the DIN Rail Latches In
Note If you are using a 15-mm DIN rail, rotate all the feet (see Figure 2-21) to the extended positions.
Otherwise, rotate all the feet to the recessed positions. Figure 2-22 shows the two DIN rails. You
can use either the 7.5-mm or the 15-mm DIN rail.
201829

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
