Catalyst 4500 E-Series Switches Installation Guide
OL-13972-02
Chapter 1 Product Overview
Catalyst 4510R+E Switch
Ta b l e 1-11 Catalyst 4510R+E Switch Features
Feature Description
Chassis Ten horizontal slots. Slots are numbered from 1 (top) to 10 (bottom).
Supervisor engines • Supports the following supervisor engines:
– Supervisor Engine 7-E
– Supervisor Engine 6L-E
– Supervisor Engine 6-E
– Supervisor Engine V-10GE
– Supervisor Engine V
Note Refer to your software release notes for the minimum software
release versions required to support the supervisor engines.
• Supervisor engines must be installed in slot 3 or in slot 4.
• Supervisor engine redundancy is supported in this chassis.
Note The Catalyst 4510R+E switch supports 1+1 supervisor engine
redundancy for integrated resiliency. With the support of stateful
switchover (SSO), the secondary supervisor engine serves as a
backup to immediately take over after a primary supervisor failure.
During the switchover, Layer 2 links are maintained transparently
without the need to renegotiate sessions.
Modules • Supports up to nine Catalyst 4500 series modules.
• Some Catalyst 4500 series modules may:
– Not be supported
– Require that you install a specific supervisor engine
– Have chassis slot restrictions
– Require a specific software release level to operate
• Check your software release notes for specific information.
Backplane 48 Gbps full duplex per slot
Port density • 10/100 (RJ-45)—384 ports
• 10/100 with PoE (RJ-45)—384 ports
• 10/100 with or without PoE (RJ-21)—384 ports
• 100FX (MT-RJ)—384 ports
• 100LX-10 (MT-RJ) or 100BX-D (LC)—384 ports
• 1000BASE-X—388 ports
• 10/100/1000BASE-T—384 ports
• 10/100/1000BASE-T with PoE—384 ports
• 10GBASE-X—34 ports
Inline power Integrated support, 820 W per switching module

Cisco Line Card 4500 E-Series Specifications

General

Brand	Cisco
Model	Line Card 4500 E-Series
Category	Switch
Language	English
