1-16
Catalyst 4500 E-Series Switches Installation Guide
OL-13972-02
Chapter 1 Product Overview
Catalyst 4510R-E Switch
Ta b l e 1-7 Catalyst 4510R-E Switch Features
Feature Description
Chassis Ten horizontal slots. Slots are numbered from 1 (top) to 10 (bottom).
Supervisor engines • Supports the following supervisor engines:
–
Supervisor Engine 7-E
–
Supervisor Engine 6L-E
–
Supervisor Engine 6-E
–
Supervisor Engine V-10GE
–
Supervisor Engine V
Note Refer to your software release notes for the minimum software
release versions required to support the supervisor engines.
• Supervisor engines must be installed in slot 3 or in slot 4.
• Supervisor engine redundancy is supported in this chassis.
Note The Catalyst 4510R-E switch supports 1+1 supervisor-engine
redundancy for integrated resiliency. With the support of stateful
switchover (SSO), the secondary supervisor engine serves as a
backup to immediately take over after a primary supervisor failure.
During the switchover, Layer 2 links are maintained transparently
without the need to renegotiate sessions.
Modules • Supports up to nine Catalyst 4500 series modules.
• Some Catalyst 4500 series modules may:
–
Not be supported
–
Require that you install a specific supervisor engine
–
Have chassis slot restrictions
–
Require a specific software release level to operate
• Check your software release notes for specific information.
Backplane 24 Gbps full duplex per slot on five slots, plus 12 Gbps full duplex per slot
on three slots (276
Gbps) with Supervisor Engine 6-E
Port density • 10/100 (RJ-45)—384 ports
• 10/100 with PoE (RJ-45)—384 ports
• 10/100 with or without PoE (RJ-21)—384 ports
• 100FX (MT-RJ)—384 ports
• 100LX-10 (MT-RJ) or 100BX-D (LC)—384 ports
• 1000BASE-X—388 ports
• 10/100/1000BASE-T—384 ports
• 10/100/1000BASE-T with PoE—384 ports
• 10GBASE-X—34 ports
Inline power Integrated support, 820 W per switching module
