A-32
Catalyst 4500 E-Series Switches Installation Guide
OL-13972-02
Appendix A Power Supply Specifications
4200 W AC-Input Power Supply
Table A-27 shows the maximum output wattage with two 4200 W AC-input power supplies operating in
combined mode.
4200 W Power Supply AC Power Cords
Table A-28 lists the specifications for the AC power cords that are available for the 4200 W AC-input
power supply.
Note All 4200 W power supply power cords have an IEC60320/C19 appliance plug at one end.
Ta b l e A-26 Redundant Mode Output
Source AC to Power Supplies +12 VDC +3.3 VDC –50 VDC Total (W)
110 VAC to one input on supply 1 and one
100
VAC to one input on power supply 2
660 W 40 W 700 W 1050 W
110 VAC to both inputs on power supply 1 and
110
VAC to both inputs on power supply 2, or
one 220
VAC input to power supply 1 and one
220
VAC input to power supply 2
1360 W 40 W 1850 W 2100 W
220 VAC to both inputs on power supply 1 and
power supply
2
1360 W 40 W 3700 W 4200 W
Ta b l e A-27 4200 W Power Supplies in Combined Mode Output
Source AC to Power Supplies W @
+12 VDC
W @
+3.3 VDC
W @
–50 VDC
Maximum (W)
Both power supplies with one input at
110
VA C
1200 W 40 W 1320 W 1870 W
One 110 VAC input to one power supply
and two 110
VAC inputs to the other
power supply
1800 W 40 W 2000 W 2730 W
Both power supplies with two 110 VA C
inputs
2200 W 40 W 3100 W 3800 W
Both power supplies with one 220 VA C
input
2200 W 40 W 3100 W 3800 W
Two 220 VAC inputs to one power supply,
one 220
VAC input to the other power
supply
2200 W 40 W 4700 W 5500 W
Both power supplies with two 220 VA C
inputs
2200 W 40 W 6200 W 7600 W
