Catalyst 4500 E-Series Switches Installation Guide
OL-13972-02
Chapter 1 Product Overview
Catalyst 4507R+E Switch
Ta b l e 1-9 Catalyst 4507R+E Switch Features
Feature Description
Chassis Seven horizontal slots. Slots are numbered from 1 (top) to 7 (bottom).
Supervisor engines • Supports the following supervisor engines:
– Supervisor Engine 7-E
– Supervisor Engine 6L-E
– Supervisor Engine 6-E
– Supervisor Engine V-10GE
– Supervisor Engine V
– Supervisor Engine IV
– Supervisor Engine II-Plus-10GE
– Supervisor Engine II-Plus
Note Refer to your software release notes for the minimum software
release versions required to support the supervisor engines.
• Supervisor engines must be installed in slot 3 or in slot 4.
• Supervisor engine redundancy is supported in this chassis.
Note The Catalyst 4507R+E switch supports 1+1 supervisor-engine
redundancy. With the support of stateful switchover (SSO), the
secondary supervisor engine serves as a backup to immediately take
over after a primary supervisor failure. During the switchover,
Layer
2 links are maintained transparently without the need to
renegotiate sessions.
Modules • Supports up to six Catalyst 4500 series modules.
• Some Catalyst 4500 series modules may:
– Not be supported
– Require that you install a specific supervisor engine
– Have chassis slot restrictions
– Require a specific software release level to operate
• Check your software release notes for specific information.
Backplane 48 Gbps full duplex per slot
