4-3
Catalyst 4500 E-Series Switches Installation Guide
OL-13972-02
Chapter 4 Removal and Replacement Procedures
Removing and Installing the AC-Input Power Supplies
Figure 4-1 AC-Input Power Supply (Single-Input)
Figure 4-2 Dual-Input AC-Input Power Supply (4200 W and 6000 W)
Required Tools
You need a flathead or Phillips-head screwdriver to perform these procedures.
1 AC in receptacle 3 Captive installation screws
2 Power on/off switch
231375
1
2
3
1 AC input 2 receptacle 4 AC input 1 receptacle
2 AC input 2 on/off switch 5 Captive installation screws
3 AC input 1 on/off switch
231376
100-120V-
12A
50/60Hz
100-120V-
12A
50/60Hz
INPUT 1
OK
INPUT 2
OK
POE ENABLED
4600ACV
OUTP{UT FAI:
FAN OK
4
5
3
2
1
