Catalyst 4500 E-Series Switches Installation Guide
OL-13972-02
Chapter 1 Product Overview
Catalyst 4503-E Switch
Inline power Integrated support, 820 W per switching module
Fan tray The chassis supports one hot-swappable fan tray. One fan tray model is
available:
WS-X4593-E
The fan tray contains six individual fans. The individual fans are not
field replaceable; you must replace the fan tray in the event of a fan
failure.
Fan tray STATUS LED (located on the fan tray front panel)
Red—One or more individual fans have failed.
Green—Fan tray is operating normally.
Power supply Supports one or two power supplies. The following power supplies are
supported:
1000 W AC-input power supply (PWR-C45-1000AC)
1400 W AC-input power supply (PWR-C45-1400AC)
1300 W AC-input power supply (PWR-C45-1300ACV)
2800 W AC-input power supply (PWR-C45-2800ACV)
4200 W AC-input power supply (PWR-C45-4200ACV)
6000 W AC-input power supply (PWR-C45-6000ACV)
1400 W DC-input power supply, triple-input (PWR-C45-1400DC)
1400 W DC-input power supply with integrated PEM
(PWR-C45-1400DC-P)
External AC power shelf (WS-P4502-1PSU)
All Catalyst 4500 series AC-input power supplies require single-phase
source AC. Source AC can be out of phase between multiple power
supplies or multiple AC-power plugs on the same power supply because
all AC power supply inputs are isolated.
Single power supplies are installed in the left power supply bay. The
second power supply is installed in the right power supply bay.
Note For proper operation of the power supply OUTPUT FAIL LED,
systems with single power supplies must be configured with a
minimum of one fan tray and one supervisor engine. Systems with
dual power supplies must have a minimum configuration of one fan
tray, one supervisor engine, and one additional module. Failure to
meet these minimum configuration requirements can cause a false
power supply output fail signal.
Table 1-1 Catalyst 4503-E Switch Features (continued)
