Create the Site Log prior to the installation. See the Site Log and Manufactures section for more information
on the Site Log as well as a sample Site Log that can be used to make copies.
Receiving the Cisco NCS 560-4 Router
Each Cisco NCS 560-4 Router chassis is shipped in a container.
Figure 11:
Figure 12: Cisco NCS 560-4 Router Packaged for Shipping
Tray2Bottom and Top foam1
——Roll End Lock Front
(RELF)
3
Cisco NCS 560-4 Router Hardware Installation Guide
35
Preparing for Installation
Receiving the Cisco NCS 560-4 Router
