Appendix B Transceivers and Module Connectors
10-Gigabit X2 Transceivers
10GBASE-DWDM X2 Transceivers
The Dense Wavelength Division Multiplexing (DWDM) X2 transceivers are part of a DWDM optical
network to provide high-capacity bandwidth across a fiber-optic network. There are 32 fixed-wavelength
DWDM X2 transceivers that support the International Telecommunications Union (ITU) 100-GHz
wavelength grid. These transceivers have duplex SC connectors. DWDM X2 transceivers can transmit
and receive optical signals up to 50 miles (80 km) depending on the quality of the fiber-optic cable used.
DWDM X2 transceivers look like the typical 10GBASE-X X2 transceivers as shown in Figure B-2 on
page B-5.
For the specifications that differentiate the 10GBASE-DWDM X2 transceivers, see Table B-8.
Table B-7 X2 Transceiver Physical and Environmental Specifications
Characteristic Specification
Dimensions (H x W x D) 0.53 x 1.41 x 3.58 inches (13.46 x 36 x 91 mm)
Operating temperature
X2-10GB-ER
X2-10GB-LR
X2-10GB-LRM
X2-10GB-LX4
X2-10GB-SR
X2-10GB-ZR
32º to 122ºF (0º to 50ºC)
32º to 122ºF (0º to 50ºC)
32º to 158ºF (0º to 70ºC)
32º to 158ºF (0º to 70ºC)
32º to 122ºF (0º to 50ºC)
32º to 122ºF (0º to 50ºC)
Storage temperature –40º to 185º F (–40º to 85ºC)
Table B-8 DWDM X2 Transceivers
Part Number
100-GHz
ITU Channel Description
DWDM-X2-60.61= 21 10GBASE-DWDM 1560.61 nm X2
DWDM-X2-59.79= 22 10GBASE-DWDM 1559.79 nm X2
DWDM-X2-58.98= 23 10GBASE-DWDM 1558.98 nm X2
DWDM-X2-58.17= 24 10GBASE-DWDM 1558.17 nm X2
DWDM-X2-56.55= 26 10GBASE-DWDM 1556.55 nm X2
DWDM-X2-55.75= 27 10GBASE-DWDM 1555.75 nm X2
DWDM-X2-54.94= 28 10GBASE-DWDM 1554.94 nm X2
DWDM-X2-54.13= 29 10GBASE-DWDM 1554.13 nm X2
DWDM-X2-52.52= 31 10GBASE-DWDM 1552.52 nm X2
DWDM-X2-51.72= 32 10GBASE-DWDM 1551.72 nm X2
DWDM-X2-50.92= 33 10GBASE-DWDM 1550.92 nm X2
DWDM-X2-50.11= 34 10GBASE-DWDM 1550.11 nm X2
