HeightDepthWidthChassis or Module
1.42 inches (3.61 cm)Inside chassis: 10.74
inches (27.28 cm)
Ejector levers outside
chassis: 0.75 inches (1.9
cm)
Without mounting
brackets: 6.81 inches
(17.3 cm)
With mounting brackets:
7.81 inches (19.84 cm)
System controller
modules
1.75 inches (4.4 cm)Inside chassis: 16.5 inches
(41.91 cm)
Ejector levers outside
chassis: 2.5 inches (6.35
cm)
17.0 inches (43.18 cm)Line cards
16.4 inches (41.66 cm)11.7 inches (29.72 cm)2.46 inches (6.25 cm)Fabric modules
Without mounting
brackets: 16.5 inches
(41.91 cm)
With mounting brackets:
18.08 inches (45.92 cm)
5.12 inches (13.0 cm)5.04 inches (12.81 cm)Fan trays
1.75 inches (4.4 cm)Inside chassis: 17.75
inches (44.96 cm)
Ejector levers outside
chassis: 0.75 inches (1.9
cm)
5.25 inches (13.33 cm)Power supply
Weights for the Chassis, Modules, Fan Trays, and Power
Supplies
Weight per UnitComponent
150.0 lb (68.2 kg)Cisco Nexus 9508 Chassis (N9K-C9508)
—Supervisor Modules
4.84 lb (2.2 kg)Supervisor A module (N9K-SUP-A)–
5.2 lb (2.37 kg)Supervisor A+ module (N9K-SUP-A+)–
6.0 lb (2.72 kg)Supervisor B module (N9K-SUP-B)–
5.3 lb (2.39 kg)Supervisor B+ module (N9K-SUP-B+)–
1.9 lb (0.9 kg)System Controller Module (N9K-SC-A)
—Line cards that the N9K-C9508-FM fabric modules support
Cisco Nexus 9508 NX-OS Mode Switch Hardware Installation Guide
112
System Specifications
Weights for the Chassis, Modules, Fan Trays, and Power Supplies
