Cisco Nexus 9508 NX-OS - Fabric Module LEDs; Line Card LEDs

StatusColorLED
The fabric modules behind this fan tray are operational.
GreenFAB
At least one fabric module behind this fan tray is not operating or there is not a
fabric blank module with power connector (N9K-C9508-FM-Z) to provide power
to the fan tray.
Amber
No power is going to the fabric module behind this fan tray.Off
Fabric Module LEDs
The fabric modules are located behind the fan trays. The following table describes the possible states for each
of these LEDs.
StatusColorLED
The operator has activated this beacon (BCN) LED to identify this module
in the chassis.
When the operator activates the BCN/top LED, the BCN LED
on the covering fan module also activates (lights).
Note
BlueBCN/top
LED
This module is not being identified.Off
The fabric module is operational.
GreenStatus/bottom
LED
First press of the ejector button has been registeredFlashing green
The removal of the module is in progressFlashing yellow
The fabric module has a fault.Flashing red
The fabric module is booting up.Flashing amber
No power is going to the fabric module.Off
Line Card LEDs
The Beacon (BCN) and Status (STS) LEDs are located on the front, toward the left side of the module. The
Link LED for each port is located either between the two rows of ports, or if there is a single row of ports,
placed up/down between ports. Each of the Link LEDs is a triangle pointing to the port above or below the
LED. The following table describes the possible states for each of these LEDs.
StatusColorLED
The operator has activated this LED to identify this module in the
chassis.
Flashing blueBCN
This LED is not being used.Off
