All of the fabric modules in a modular switch must be of the same type.
Note
The fabric modules must be installed in specific slots as follows (installing
fabric modules in other slots can cause a module mismatch condition):
• For three modules, they must be in slots FM 2, FM 4, and FM 6
• For four modules, they must be in slots FM2, FM 3, FM 4, and FM 6
• For five modules, they can be in slots FM 2, FM 3, FM 4, FM 5, and
FM 6.
• For six modules, they are in slots FM 1, FM 2, FM 3, FM 4, FM 5,
and FM 6
Note
When using FM-G fabric modules, any empty fabric module slots should
be filled with N9K-C9508-FAN-PWR cards.
Note
When using any fabric modules other than N9K-C9508-FM-G, any empty
slots should be filled with N9K-C9508-FM-CV cards.
Note
When using N9K-C9508-FM-R2, no fabric module slots shall be left empty.
Note
For more information about Line card and fabric module compatibility, see
the Cisco Nexus 9500 Platform Line Cards and Fabric Modules Data Sheet.
Note
• Fan trays (three) (N9K-C9508-FAN) or (N9K-C9508-FAN2) in slots FAN 1 to FAN 3 (numbered from
left to right on the chassis)
• Power supplies (up to eight) in slots PS 1 to PS 8 (numbered from left to right on the chassis)
• Cisco Nexus 9500 Series 3-kW AC power supply (N9K-PAC-3000W-B)
• Cisco Nexus 9500 Series 3-kW Universal AC/DC power supply (N9K-PUV-3000W-B)
• Cisco Nexus 9500 Series 3.15-kW Dual Input Universal AC/DC power supply
(N9K-PUV2-3000W-B)
• Cisco Nexus 9500 Series 3-kW (-48 V) DC power supply (N9K-PDC-3000W-B)
Cisco Nexus 9508 NX-OS Mode Switch Hardware Installation Guide
4
Overview
