The switch can be powered by a mix of AC, DC, HVAC/HVDC power
sources.
Note
All chassis slots are numbered from left to right or from top to bottom.
Note
The following figure shows the hardware features seen from the front of the chassis.
3-kW AC, Universal
AC/DC, or DC power
supplies (AC power
supplies shown).
4Chassis LEDs1
2 vertical mounting
brackets that are used to
mount the chassis onto a
rack
5Line cards (up to 8)2
Cisco Nexus 9508 NX-OS Mode Switch Hardware Installation Guide
5
