Cisco Nexus 9508 NX-OS User Manual

Chassis handles (used
only for positioning the
chassis on the bottom
support rails—do not use
these handles for lifting
the chassis).
6Supervisor modules (1 or
2)
3
The following figure shows the hardware features seen from the rear of the chassis (one fan tray has been
removed to show the fabric modules behind the fan trays).
Grounding pad4Fan trays (3—left fan tray
that is not shown in order
to display the fabric
modules that are located
behind the fan trays).
1
Chassis handles (used
only for positioning the
chassis on the bottom
support rails—do not use
these handles for lifting
the chassis).
5Fabric modules (3 to 6
40-Gigabit modules or 4
100- or 400-Gigabit
modules)
2
Cisco Nexus 9508 NX-OS Mode Switch Hardware Installation Guide
6
Overview
Overview

Cisco Nexus 9508 NX-OS Specifications

General

Brand	Cisco
Model	Nexus 9508 NX-OS
Category	Switch
Language	English
