Cisco RV130W Administration Guide

Configuring Networking
Configuring IPv6
Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 45
3
To configure the device to be a DHCPv6 client:
STEP 1 Choose Networking > IPv6 > IPv6 WAN Configuration.
STEP 2 In the WAN Connection Type field, select Automatic Configuration-DHCPv6.
The gateway connects to the ISP's DHCPv6 server for a leased address.
STEP 3 To automate assigning prefixes to your device (the DHCP client), select the Prefix
Delegation Enable radio button.
STEP 4 Click Save.
Configuring a Static IPv6 WAN Address
If your ISP assigns you a fixed address to access the WAN, configure the device to
use a static IPv6 address.
To configure a static IPv6 WAN address:
STEP 1 Choose Networking > IPv6 > IPv6 WAN Configuration.
STEP 2 From the WAN Connection Type menu, select Static IPv6.
STEP 3 Enter this information:
STEP 4 Click Save.
IPv6 Address IPv6 address of the WAN port.
IPv6 Prefix Length Length of the IPv6 prefix (typically defined by the
ISP). The IPv6 network (subnet) is identified by the
initial bits of the address called the prefix. All hosts
in the subnetwork have the identical prefix.
For example, in the IPv6 address
2001:0DB8:AC10:FE01::, the prefix is 2001.
Default IPv6 Gateway IPv6 address of the default gateway. This is
typically the IP address of the server at the ISP.
Static DNS 1 IP address of the primary IPv6 DNS server.
Static DNS 2 IP address of the secondary IPv6 DNS server.

Cisco RV130W Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Supported network protocols	DHCP, PPPoE, PPTP, L2TP, DNS, IGMP, RSTP
Antennas quantity	2
Security algorithms	WEP, WPA, WPA2-PSK
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, USB, WAN, WLAN
Output voltage	12 V
Power source type	DC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %
