7-3
Cisco SCE 2000 4xGBE Installation and Configuration Guide
OL-7824-06
Chapter 7 Basic SCE 2000 Platform Operations
Starting the SCE 2000 Platform
Note It takes a several minutes for the SCE 2000 to boot and for the status LED to change from orange to
flashing orange or flashing green.
Step 5 Observe the initialization process. When the system boot is complete, the console screen displays a
script and system banner similar to the following:
Cisco Internetwork Operating System Software
IOS (tm) 7300 Software (C7300-JS-M), Version 12.1(9), CISCO RELEASED VERSION
Copyright (c) 1986-2006 by Cisco Systems, Inc.
Compiled Tue 17-MAY-06 01:51 by biff
Image text-base:0x40008970, data-base:0x40BF8000
Step 6 When you start up the SCE 2000 platform for the first time, the system automatically enters the setup
wizard, which prompts you for configuration information for initial system configuration. On the
console terminal, after the system displays the system banner and hardware configuration, you will see
the System Configuration Dialog prompt. (Refer to Connecting the Management Interfaces and
Performing Initial System Configuration for a complete description of the setup wizard.)
You have the option of proceeding with the setup wizard to configure the system, or exiting from setup
and using configuration commands to configure global (system-wide) and interface-specific parameters.
You do not have to configure the interfaces immediately.
Final Tests
The procedures for performing the final tests to verify that the SCE 2000 is functioning properly are
explained in the following sections:
• How to Verify Operational Status
• How to View the User Log Counters
How to Verify Operational Status
After all the ports are connected, verify that the SCE 2000 is not in a Warning state.
• Examples for Verifying Operational Status
SUMMARY STEPS
1. On the SCE 2000 Front panel, examine that the Status LED is flashing green.
2. To display the operation status of the system, at the SCE 2000# prompt, type show system
operation-statusand press Enter.
DETAILED STEPS
Step 1 On the SCE 2000 Front panel, examine that the Status LED is flashing green.
Step 2 To display the operation status of the system, at the SCE 2000# prompt, type show system
operation-statusand press Enter.
A message displaying the operation status of the system appears. If the system is operating in order, the
following message appears:
