3-6
Cisco SCE 2000 4xGBE Installation and Configuration Guide
OL-7824-06
Chapter 3 Information About Topology
Information About Topology Considerations
Figure 3-2 Single SCE Platform Dual Link Inline Topology
This topology supports both monitoring and control functionality, and is referred to as “inline”
connection mode.
Single Link: Receive-only Topology
In this topology, an optical splitter resides physically on the GBE link between the subscribers and the
network. The traffic passes through the optical splitter, which splits traffic to the SCE 2000 . The SCE
2000, therefore, only receives traffic and does not transmit.
LINK
RX
Cisco SCE 2000 Series
4xGBE
TX
RX
MM TX
LINK
RX
TX
RX
MM TX
LINK
RX
TX
RX
MM TX
LINK
RX
TX
RX
MM
TX
GBE-1
SUB LINE
NET
PWR B
STATUS
PWR A
BYPASS
GBE-2
SUB
LINE/CASCADE NET
RouterRouter
Subscriber
92799
Network
Router
Link 1
Link 2
Router
Subscriber
Network
