4-19
Cisco SCE 2000 4xGBE Installation and Configuration Guide
OL-7824-06
Chapter 4 Installation and Maintenance
How to Replace the Power Supply Unit
4. Remove the screw from one DC power line input lead receptacle and pull the lead from the
connector. Repeat this step for the remaining lead.
DETAILED STEPS
Step 1 Place the on/off switch on the DC-input power supply in the OFF position.
Step 2 Make sure that that power is removed from the DC circuit by turning off the circuit breaker or switch
providing power to the DC-input power supply.
Step 3 Observe that the corresponding Power LED on the front panel turns off.
Step 4 Remove the screw from one DC power line input lead receptacle and pull the lead from the connector.
Repeat this step for the remaining lead.
What to Do Next
This completes the procedure for powering down an DC-input power supply unit on a SCE 2000
platform. Proceed to How to Remove the Power Supply Unit.
How to Remove the Power Supply Unit
To remove the AC-input or DC-input power supply unit from the SCE 2000 platform, complete the
following steps:
SUMMARY STEPS
1. Using a 1/4-inch flat-blade screwdriver, loosen the captive installation screw on the corner of the
faceplate of the power supply.
2. Grasp the power supply handle and pull the power supply from the router.
DETAILED STEPS
Step 1 Using a 1/4-inch flat-blade screwdriver, loosen the captive installation screw on the corner of the
faceplate of the power supply.
Step 2 Grasp the power supply handle and pull the power supply from the router.
How to Replace the Power Supply Unit
Note Do not mix AC-input and DC-input power supply units in the same SCE 2000 platform.
