Cisco SCE 2000 4xGBE Installation and Configuration Guide
OL-7824-06
Chapter 2 Introduction to the SCE Platform
Information About The SCE Platform
AUX 1 RS-232 RJ-45 port used
by technicians
GBE ports 1-4 4 GigabitEthernet ports
for connecting to the
line and/or cascading
two devices
CLI designation:
interface
GigabitEthernet 0/1
through 0/4
Table 2-3 SCE 2000 LED Groups
LED Groups Description
Power A
• Continuous green — Power supply A is
functioning normally
• Red — Power supply A present, but
malfunctioning
• Unlit — Power supply A is either not present
or has failed.
Power B
• Continuous green — Power supply B is
functioning normally
• Red — Power supply B present, but
malfunctioning
• Unlit — Power supply B is either not present
or has failed.
Status The Status LED indicates the operational status of
the SCE 2000 system, as follows:
• Unlit — indicates no power from either power
unit.
• Orange — indicates that the system is booting
up.
• Flashing green — indicates that the system is
fully operational.
• Flashing orange — indicates that the system is
operational, but is in a warning state.
• Red — indicates that there is a problem or
failure
Note that Alarms are hierarchical: Failure takes
precedence over Warning, which takes precedence
over operational.
Table 2-2 SCE 2000 Ports
Port Quantity Description Connect This Port To…
