Cisco SCE 2000 4xGBE Installation and Configuration Guide
OL-7824-06
Chapter 5 Connecting the Management Interfaces and Performing Initial System Configuration
Initial System Configuration
The procedure described below is a presentation of all the questions in the topology configuration. In
actual practice, all questions may not be presented for a particular configuration, depending on the
topology deployed.
Study the examples that follow to understand the procedure for various topologies.
SUMMARY STEPS
1. Enter the topology configuration menu.
2. Specify the connection mode.
3. Specify the deployment type.
4. Specify the physically-connected-link index.
5. Specify the SCE 2000 priority.
6. Specify the On-failure link behavior.
7. Specify the status of the SCE 2000 after abnormal boot.
DETAILED STEPS
Step 1 Enter the topology configuration menu.
Would you like to enter the Topology configuration menu? [no]: y
Type yand press Enter.
The topology configuration dialog begins.
Step 2 Specify the connection mode.
• To define inline connection mode, press Enter.
• To define receive-only connection mode, type 2and press Enter.
Enter Connection mode:
1- inline
2- receive-only
Enter your choice [1]:
Step 3 Specify the deployment type.
• To specify a Single-SCE Platform deployment, press Enter.
• To specify a Cascade deployment, type yand press Enter.
Is this a cascade deployment? [no]:
Step 4 Specify the physically-connected-link index.
• To specify link-0 , press Enter.
• To specify link-1 , type 1and press Enter.
Enter Physically connected link:
0- link-0
1- link-1
Enter your choice [0]:
Step 5 Specify the SCE 2000 priority.
• To specify Primary , press Enter.
• To specify Secondary , type 2and press Enter.
