Chapter 5 Connecting the Management Interfaces and Performing Initial System Configuration
Connecting the Management Interface
DETAILED STEPS
Step 1 After you connect the cable to the appropriate Mng port and to your network, check the relevant Mng
port LEDS.
There are two Mng LEDs — Link/Active, and 10/100/1000 (refer to Front Panel).
At this point, check that the Link/Active LED is green.
The state of the 10/100/1000 LED will depend on the Ethernet network settings.
Green indicates 100 Mbps and ‘Off’ indicates 10 Mbps.
Step 2 Test connectivity. From the host that you intend to use for remote management, ping to the SCE 2000
by typing ping and the SCE 2000 IP address, and pressing Enter (see the example, below).
Note Please note that only above, is performed from the remote management host (Mng port connection).
This verifies that an active connection exists between the specified station and the management port.
The ping program sends an echo request packet to an IP address and then awaits a reply. Ping output can
help you evaluate path-to-host reliability, delays over the path, and whether the host can be reached or
is functioning.
EXAMPLE:
The following example displays a typical ping response where the target IP address is 10.1.1.201.
C:\>ping 10.1.1.201
pinging 10.1.1.201 ...
PING 10.1.1.201: 56 data bytes
64 bytes from host (10.1.1.201): icmp_seq=0. time=0. ms
64 bytes from host (10.1.1.201): icmp_seq=1. time=0. ms
64 bytes from host (10.1.1.201): icmp_seq=2. time=0. ms
64 bytes from host (10.1.1.201): icmp_seq=3. time=0. ms
----10.1.1.201 PING Statistics----
4 packets transmitted, 4 packets received, 0% packet loss
round-trip (ms) min/avg/max = 0/0/0
