Administration: Discovery
Discover - LLDP
Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 122
8
STEP 3 On the bottom of the page, click LLDP Port Status Table to see the details in the LLDP Port
Status Table (see LLDP Port Settings).
LLDP Neighbor Information
The LLDP Neighbor Information page contains information that was received from
neighboring devices.
After timeout (based on the value received from the neighbor Time To Live TLV during which
no LLDP PDU was received from a neighbor), the information is deleted.
To view the LLDP neighbors information:
STEP 1 Click Administration > Discovery - LLDP > LLDP Neighbor Information.
STEP 2 Select the interface for which LLDP neighbor information is to be displayed.
This page displays the following fields for the selected interface:
• Local Port—Number of the local port to which the neighbor is connected.
• Chassis ID Subtype—Type of chassis ID (for example, MAC address).
• Chassis ID—Identifier of the 802 LAN neighboring device's chassis.
• Port ID Subtype—Type of the port identifier that is shown.
• Port ID—Identifier of port.
• System Name—Published name of the device.
• Time to Live—Time interval (in seconds) after which the information for this neighbor
is deleted.
STEP 3 Select a local port, and click Details.
The LLDP Neighbor Information page contains the following fields:
Port Details
• Local Port—Port number.
• MSAP Entry—Device Media Service Access Point (MSAP) entry number.
Basic Details
• Chassis ID Subtype—Type of chassis ID (for example, MAC address).
