Cisco SG350X-24 User Manual

IP Configuration: RIPv2
Configuring RIP
Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 402
17
Configuring RIP
The following actions can be performed.
• Mandatory actions:
- Globally enable/disable RIP protocol, using the RIPv2 Properties page.
- Enable/disable RIP protocol on an IP interface, using the RIPv2 Settings page.
• Optional actions (if these are not performed, default values are used by the system)
- Enable/disable RIP to advertise static or connected routes and its metric on the IP
interface, using the RIPv2 Properties page.
- Configure the offset added to the metric for incoming routes on an IP interface,
using theRIPv2 Settings page.
- Enable passive mode on an IP interface, using the RIPv2 Settings page.
- Control which routes are processed in the incoming/outgoing routing updates by
specifying an IP address list on the IP interface (see Access Lists).
- Advertise default route entries on the IP interface, using the RIPv2 Settings page.
- Enable RIP authentication on an IP Interface, using the RIPv2 Settings page.
The following pages are described:
• RIPv2 Properties
• RIPv2 Settings
• RIPv2 Statistic
• RIPv2 Peers Database
RIPv2 Properties
NOTE This feature is only supported on Sx550X/SG550XG devices.
To enable/disable RIP on the device.
STEP 1 Click IP Configuration > IPv4 Management and Interfaces> RIPv2 > RIPv2 Properties.
STEP 2 Select the following options as required:
• RIP—The following options are available:

Cisco SG350X-24 Specifications

General

Model	SG350X-24
Layer	Layer 3
Power Supply	Internal
Rack Mountable	Yes
RAM	512 MB
Flash Memory	256 MB
MAC Address Table	16K entries
Power over Ethernet (PoE)	No
Uplink Ports	4 x 10 Gigabit Ethernet
Jumbo Frame Support	Yes
Power Dedicated to PoE	Not applicable
Dimensions	440 x 44 x 350 mm
Stacking	Yes
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Relative Humidity	10% to 90% (non-condensing)
Power Consumption	30W (maximum)
