VLAN Management
Customer Port Multicast TV VLAN
239 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
11
STEP 1 Click VLAN Management > Access Port Multicast TV VLAN > Multicast Group to
VLAN.
The following fields are displayed:
• Multicast Group—IP address of the Multicast group.
• Multicast TV VLAN—VLAN to which the Multicast packets are assigned.
STEP 2 Click Add to associate a Multicast group to a VLAN. Any VLAN can be selected. When a
VLAN is selected, it becomes a Multicast TV VLAN.
STEP 3 Click Apply. Multicast TV VLAN settings are modified, and written to the Running
Configuration file.
Port Multicast VLAN Membership
To define the Multicast TV VLAN configuration:
STEP 1 Click VLAN Management > Access Port Multicast TV VLAN > Port Multicast VLAN
Membership.
STEP 2 Select a VLAN from Multicast TV VLAN.
STEP 3 Select an interface from Interface Type.
STEP 4 The Candidate Access Ports list contains all access ports configured on the device. Move the
required ports to the Member Access Ports field.
STEP 5 Click Apply. Multicast TV VLAN settings are modified, and written to the Running
Configuration file.
Customer Port Multicast TV VLAN
A triple play service provisions three broadband services, over a single broadband connection:
• High-speed Internet access
• Video
• Vo i c e

Cisco SG350X-24 Specifications

General

Model	SG350X-24
Layer	Layer 3
Power Supply	Internal
Rack Mountable	Yes
RAM	512 MB
Flash Memory	256 MB
MAC Address Table	16K entries
Power over Ethernet (PoE)	No
Uplink Ports	4 x 10 Gigabit Ethernet
Jumbo Frame Support	Yes
Power Dedicated to PoE	Not applicable
Dimensions	440 x 44 x 350 mm
Stacking	Yes
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Relative Humidity	10% to 90% (non-condensing)
Power Consumption	30W (maximum)
