VLAN Management
Regular VLANs
213 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
11
The port mode for each port or LAG appears with its current port mode (Access, Trunk,
General, Private-Host, Private-Promiscuous or Customer) configured from the Interface
Settings page.
Each port or LAG appears with its current registration to the VLAN.
STEP 3 Change the registration of an interface to the VLAN by selecting its Interface Name in the list
of interfaces.
The following fields are displayed:
• VLAN Mode—Displays port type of ports in the VLAN.
• Membership Type: Select one of the following options:
- Forbidden—The interface is not allowed to join the VLAN even from GVRP
registration. When a port is not a member of any other VLAN, enabling this option
on the port makes the port part of internal VLAN 4095 (a reserved VID).
- Excluded—The interface is currently not a member of the VLAN. This is the default
for all the ports and LAGs when the VLAN is newly created.
- Tagged—The interface is a tagged member of the VLAN.
- Untagged—The interface is an untagged member of the VLAN. Frames of the
VLAN are sent untagged to the interface VLAN.
- Multicast MTV VLAN—The interface used for Digital TV using Multicast IP. The
port joins the VLAN with a VLAN tag of Multicast TV VLAN. See Access Port
Multicast TV VLAN for more information.
• PVID—Select to set the PVID of the interface to the VID of the VLAN. PVID is a per-
port setting.
STEP 4 Click Apply. The interfaces are assigned to the VLAN, and written to the Running
Configuration file.
You can continue to display and/or configure port membership of another VLAN by selecting
another VLAN ID.
Port VLAN Membership
The Port VLAN Membership page displays all ports on the device along with a list of VLANs
to which each port belongs.
