STEP 4 Click Apply. The group is added, and written to the Running Configuration file.
Subnet-based Groups to VLAN
To map a subnet group to a port, the port must not have DVA configured on it (see Interface
Settings).
Several groups can be bound to a single port, with each port being associated to its own
VLAN.
It is possible to map several groups to a single VLAN as well.
To map the subnet group to a VLAN:
STEP 1 Click VLAN Management > VLAN Groups > Subnet-Based Groups to VLAN.
The currently-defined mappings are displayed.
STEP 2 To associate an interface with a protocol-based group and VLAN, click Add.
The Group Type field displays the type of group being mapped.
STEP 3 Enter the following fields.
• Interface—Port or LAG number assigned to VLAN according to protocol-based group.
• Group ID—Protocol group ID.
• VLAN ID—Attaches the specified group for this interface to a user-defined VLAN ID.
STEP 4 Click Apply. The subnet-based group ports are mapped to VLANs, and written to the Running
Configuration file.
Protocol-based VLAN Groups Overview
Groups of protocols can be defined and then bound to a port. After the protocol group is bound
to a port, every packet originating from a protocol in the group is assigned the VLAN that is
configured in the Protocol-Based Groups page.
