IP Configuration
IPv4 Management and Interfaces
Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 282
15
• File Server IP Address (siaddr)—Enter the IP address of the TFTP/SCP server from
which the configuration file is downloaded.
• File Server Host Name (sname/Option 66)—Enter the name of the TFTP/SCP server.
• Configuration File Name (file/Option 67)—Enter the name of the file that is used as
a configuration file.
STEP 4 Click Apply. The Running Configuration file is updated.
Excluded Addresses
By default, the DHCP server assumes that all pool addresses in a pool may be assigned to
clients. A single IP address or a range of IP addresses can be excluded. The excluded
addresses are excluded from all DHCP pools.
To define an excluded address range:
STEP 1 Click IP Configuration > IPv4 Management and Interfaces > DHCP Server > Excluded
Addresses.
The previously-defined excluded IP addresses are displayed.
STEP 2 To add a range of IP addresses to be excluded, click Add, and enter the fields:
• Start IP Address—First IP address in the range of excluded IP addresses.
• End IP Address—Last IP address in the range of excluded IP addresses.
STEP 3 Click Apply. The Running Configuration file is updated.
Static Hosts
You might want to assign some DHCP clients a permanent IP address that never changes. This
client is then known as a static host.

Cisco SG350X-24 Specifications

General

Model	SG350X-24
Layer	Layer 3
Power Supply	Internal
Rack Mountable	Yes
RAM	512 MB
Flash Memory	256 MB
MAC Address Table	16K entries
Power over Ethernet (PoE)	No
Uplink Ports	4 x 10 Gigabit Ethernet
Jumbo Frame Support	Yes
Power Dedicated to PoE	Not applicable
Dimensions	440 x 44 x 350 mm
Stacking	Yes
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Relative Humidity	10% to 90% (non-condensing)
Power Consumption	30W (maximum)
