Cisco SG350X-24 User Manual

Security: 802.1X Authentication
Web Authentication Customization
331 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
17
STEP 13 Click Edit Success Page.
Figure 5 The following page is displayed
.
STEP 14 Click the Edit button on the right side of the page.
STEP 15 Enter the Success Message, which is the text that will be displayed if the end user successfully
logs in.
STEP 16 Click Apply and the settings are saved to the Running Configuration file.
To preview the login or success message, click Preview.
To set the default language of the GUI interface as the default language for Web-based
authentication, click Set Default Display Language.

Cisco SG350X-24 Specifications

General

Model	SG350X-24
Layer	Layer 3
Power Supply	Internal
Rack Mountable	Yes
RAM	512 MB
Flash Memory	256 MB
MAC Address Table	16K entries
Power over Ethernet (PoE)	No
Uplink Ports	4 x 10 Gigabit Ethernet
Jumbo Frame Support	Yes
Power Dedicated to PoE	Not applicable
Dimensions	440 x 44 x 350 mm
Stacking	Yes
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Relative Humidity	10% to 90% (non-condensing)
Power Consumption	30W (maximum)
