Cisco SG350X-24 User Manual

Security: IPv6 First Hop Security
Configuring IPv6 First Hop Security through Web GUI
557 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
25
STEP 4 To configure system-defined default policies or existing user defined policy select the policy
in the policy table and click Edit.
STEP 5 To attach this policy to an interface:
• Attach Policy to VLAN—Click to jump to Policy Attachment (VLAN) page where
you can attach this policy to a VLAN.
• Attach Policy to Interface—Click to jump to Policy Attachment (Port) page where you
can attach this policy to a port.
DHCPv6 Guard Settings
Use the DHCPv6 Guard Settings page to enable the DHCPv6 Guard feature on a specified
group of VLANs and to set the global configuration values for this feature. If required, a
policy can be added or the system-defined default DHCPv6 Guard policies can be configured
in this page.
To configure DHCPv6 Guard:
STEP 1 Click Security > IPv6 First Hop Security > DHCPv6 Guard Settings.
The currently-defined polices are displayed. For each policy, its Policy Type is displayed,
which indicates whether it is a default or user-defined policy.
STEP 2 Enter the following global configuration fields:
• DHCPv6 Guard VLAN List—Enter one or more VLANs on which DHCPv6 Guard is
enabled.
• Device Role—Displays the device role. See definition in the Add page.
• Minimal Preference—This field indicates whether the DHCPv6 Guard policy will
check the minimum advertised preference value of the packet received.
- No Verification—Disables verification of the minimum advertised preference value
of the packet received.
- User Defined—Verifies that the advertised preference value is greater than or equal
to this value. This value must be less than the Maximal Preference value.
• Maximal Preference—This field indicates whether the DHCPv6 Guard policy will
check the maximum advertised preference value of the packet received. This value must
be greater than the Minimal Preference value.
- No Verification—Disables verification of the lower boundary of the hop count limit.

Cisco SG350X-24 Specifications

General

Model	SG350X-24
Layer	Layer 3
Power Supply	Internal
Rack Mountable	Yes
RAM	512 MB
Flash Memory	256 MB
MAC Address Table	16K entries
Power over Ethernet (PoE)	No
Uplink Ports	4 x 10 Gigabit Ethernet
Jumbo Frame Support	Yes
Power Dedicated to PoE	Not applicable
Dimensions	440 x 44 x 350 mm
Stacking	Yes
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Relative Humidity	10% to 90% (non-condensing)
Power Consumption	30W (maximum)
