Cisco SG350X-24 User Manual

Access Control
ACL Binding
587 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
26
STEP 5 Enter the following for input and output ACLs:
Input ACL
• MAC-Based ACL—Select a MAC-based ACL to be bound to the interface.
• IPv4-Based ACL—Select an IPv4-based ACL to be bound to the interface.
• IPv6-Based ACL—Select an IPv6-based ACL to be bound to the interface.
• Default Action—Select one of the following options:
- Deny Any—If packet does not match an ACL, it is denied (dropped).
- Permit Any—If packet does not match an ACL, it is permitted (forwarded).
NOTE Default Action can be defined only if IP Source Guard is not activated on the
interface.
Output ACL
• MAC-Based ACL—Select a MAC-based ACL to be bound to the interface.
• IPv4-Based ACL—Select an IPv4-based ACL to be bound to the interface.
• IPv6-Based ACL—Select an IPv6-based ACL to be bound to the interface.
• Default Action—Select one of the following options:
- Deny Any—If packet does not match an ACL, it is denied (dropped).
- Permit Any—If packet does not match an ACL, it is permitted (forwarded).
NOTE Default Action can be defined only if IP Source Guard is not activated on the
interface.
STEP 6 Click Apply. The ACL binding is modified, and the Running Configuration file is updated.
NOTE If no ACL is selected, the ACL(s) that is previously bound to the interface are unbound.

Cisco SG350X-24 Specifications

General

Model	SG350X-24
Layer	Layer 3
Power Supply	Internal
Rack Mountable	Yes
RAM	512 MB
Flash Memory	256 MB
MAC Address Table	16K entries
Power over Ethernet (PoE)	No
Uplink Ports	4 x 10 Gigabit Ethernet
Jumbo Frame Support	Yes
Power Dedicated to PoE	Not applicable
Dimensions	440 x 44 x 350 mm
Stacking	Yes
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Relative Humidity	10% to 90% (non-condensing)
Power Consumption	30W (maximum)
