Quality of Service
General
Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 356
20
To map DSCP to queues:
STEP 1 Click Quality of Service > General > DSCP to Queue.
The DSCP to Queue page contains Ingress DSCP. It displays the DSCP value in the incoming
packet and its associated class.
STEP 2 Select the Output Queue (traffic forwarding queue) to which the DSCP value is mapped.
STEP 3 Click Apply. The Running Configuration file is updated.
Bandwidth
The Bandwidth page displays bandwidth information for each interface.
To view the bandwidth information:
STEP 1 Click Quality of Service > General > Bandwidth.
The fields in this page are described in the Edit page below, except for the following fields:
• Ingress Rate Limit:
Queue
7 78 65431
DSCP
60 52 44 36 28 20 12 4
Queue
7 78 65431
DSCP
59 51 43 35 27 19 11 3
Queue
7 78 65431
DSCP
58 50 42 34 26 18 10 2
Queue
7 78 65431
DSCP
57 49 41 33 25 17 9 1
Queue
7 78 65431
DSCP
56 48 40 32 24 16 8 0
Queue
7 77 87712

Cisco SG350X-24 Specifications

General

Model	SG350X-24
Layer	Layer 3
Power Supply	Internal
Rack Mountable	Yes
RAM	512 MB
Flash Memory	256 MB
MAC Address Table	16K entries
Power over Ethernet (PoE)	No
Uplink Ports	4 x 10 Gigabit Ethernet
Jumbo Frame Support	Yes
Power Dedicated to PoE	Not applicable
Dimensions	440 x 44 x 350 mm
Stacking	Yes
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Relative Humidity	10% to 90% (non-condensing)
Power Consumption	30W (maximum)
