SNMP
Views
365 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
21
Views can be attached to groups in the Groups page or to a community which employs basic
access mode through the Communities page.
To define SNMP views:
STEP 1 Click SNMP > Views.
The following fields are displayed for each view:
• Object ID Subtree—Node in the MIB tree that is included or excluded in the view.
• Object ID Subtree View—Whether the node is Included or Excluded.
STEP 2 Click Add to define new views.
STEP 3 Enter the parameters.
• View Name—Enter a view name between 0-30 characters.
• Object ID Subtree—Select the node in the MIB tree that is included or excluded in the
selected SNMP view. The options to select the object are as follows:
- Select from list—Enables you to navigate the MIB tree. Press the Up arrow to go to
the level of the selected node's parent and siblings; press the Down arrow to descend
to the level of the selected node's children. Click nodes in the view to pass from one
node to its sibling. Use the scrollbar to bring siblings in view.
- User Defined—Enter an OID not offered in the Select from list option.
STEP 4 Select or deselect Include in view. If this is selected, the selected MIBs are included in the
view, otherwise they are excluded.
STEP 5 Click Apply.
STEP 6 In order to verify your view configuration, select the user-defined views from the Filter: View
Name list. The following views exist by default:
• Default—Default SNMP view for read and read/write views.
• DefaultSuper—Default SNMP view for administrator views.
