SNMP
Notification Recipients
Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 374
21
• Filter Name—Select the SNMP filter that defines the information contained in traps
(defined in the Notification Filterpage).
STEP 5 Click Apply. The SNMP Notification Recipient settings are written to the Running
Configuration file.
SNMPv3 Notification Recipients
To define a recipient in SNMPv3:
STEP 1 Click SNMP > Notification Recipients SNMPv3.
This page displays recipients for SNMPv3.
• Informs IPv4 Source Interface—Select the source interface whose IPv4 address will
be used as the source IPv4 address in inform messages for communication with IPv4
SNMP servers.
• Traps IPv4 Source Interface—Select the source interface whose IPv6 address will be
used as the source IPv6 address in trap messages for communication with IPv6 SNMP
servers.
• Informs IPv6 Source Interface—Select the source interface whose IPv4 address will
be used as the source IPv4 address in inform messages for communication with IPv4
SNMP servers.
• Traps IPv6 Source Interface—Select the source interface whose IPv6 address will be
used as the source IPv6 address in trap messages for communication with IPv6 SNMP
servers.
STEP 2 Click Add.
STEP 3 Enter the parameters.
• Server Definition—Select whether to specify the remote log server by IP address or
name.
• IP Version—Select either IPv4 or IPv6.
• IPv6 Address Type—Select the IPv6 address type (if IPv6 is used). The options are:

Cisco SG350X-24 Specifications

General

Model	SG350X-24
Layer	Layer 3
Power Supply	Internal
Rack Mountable	Yes
RAM	512 MB
Flash Memory	256 MB
MAC Address Table	16K entries
Power over Ethernet (PoE)	No
Uplink Ports	4 x 10 Gigabit Ethernet
Jumbo Frame Support	Yes
Power Dedicated to PoE	Not applicable
Dimensions	440 x 44 x 350 mm
Stacking	Yes
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Relative Humidity	10% to 90% (non-condensing)
Power Consumption	30W (maximum)
