Cisco SG350X-24 User Manual

Smart Network Application (SNA)
DAC Workflow
Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 689
29
The report displays the following fields:
Field Val ue Comments
Device The device identifiers (Host name, IP
address)
Action Possible actions for DAC server:
• Enable RADIUS server
• Disable RADIUS server
• Update client list
• Create RADIUS server group
• Delete RADIUS server group
Possible actions for DAC client:
• Add RADIUS server connection
• Update RADIUS server connection
• Remove RADIUS server connection
• Update 802.1x settings
• Update interface authentication
settings
• Update interface host and session
settings
It is possible (and likely) for
multiple actions to appear for
each device.
Each action can have its own
status.
Warnings Possible warnings for DAC server include:
• Selected IP interface is dynamic.
Possible warnings for DAC clients include:
• Device is already a client of a
different RADIUS server.
• No ports are selected.
Warnings also contain links
to the sections of the DAC
where they can be addressed.
Changes can be applied when
warnings are present.
Status • Pending
• Success
• Failure
When the status is a failure,
the error message is shown
for the action.

Cisco SG350X-24 Specifications

General

Model	SG350X-24
Layer	Layer 3
Power Supply	Internal
Rack Mountable	Yes
RAM	512 MB
Flash Memory	256 MB
MAC Address Table	16K entries
Power over Ethernet (PoE)	No
Uplink Ports	4 x 10 Gigabit Ethernet
Jumbo Frame Support	Yes
Power Dedicated to PoE	Not applicable
Dimensions	440 x 44 x 350 mm
Stacking	Yes
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Relative Humidity	10% to 90% (non-condensing)
Power Consumption	30W (maximum)
