Cisco SG500-28 Administration Guide

Administration: Discovery
Configuring LLDP
Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3 140
9
• Enabled—Enabled Port and Protocol VLAN IDs.
VLAN IDs
• VID—Port and Protocol VLAN ID.
• VLAN Names—Advertised VLAN names.
Protocol IDs
• Protocol ID Table—Advertised protocol IDs.
Location Information
Enter the following data structures in hexadecimal as described in section
10.2.4 of the ANSI-TIA-1057 standard:
• Civic—Civic or street address.
• Coordinates—Location map coordinates—latitude, longitude, and altitude.
• ECS ELIN—Device’s Emergency Call Service (ECS) Emergency Location
Identification Number (ELIN).
• Unknown—Unknown location information.
Network Policies
• Application Type—Network policy application type, for example, Voice.
• VLAN ID—VLAN ID for which the network policy is defined.
• VLAN Type—VLAN type, Tagged or Untagged, for which the network policy
is defined.
• User Priority—Network policy user priority.
• DSCP—Network policy DSCP.
Accessing LLDP Statistics
The LLDP Statistics page displays LLDP statistical information per port.
To view the LLDP statistics:

Cisco SG500-28 Specifications

General

Ports	28
Port Type	Gigabit Ethernet
Layer	Layer 3
Switching Capacity	56 Gbps
PoE Support	No
Form Factor	Rack-mountable
RAM	256 MB
Flash Memory	32 MB
Power Supply	Internal
Jumbo Frame Support	9KB
VLAN Support	Yes
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity	10% to 90% non-condensing
Dimensions	17.3 x 10.2 x 1.7 in (440 x 260 x 44 mm)
MAC Address Table Size	16, 000 entries
