Status and Statistics
Viewing 802.1X EAP Statistics
Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3 16
2
To clear statistics counters:
• Click Clear Interface Counters to clear the selected counters.
• Click View All Interfaces Statistics to see all ports on a single page.
Viewing 802.1X EAP Statistics
The 802.1x EAP page displays detailed information regarding the EAP (Extensible
Authentication Protocol) frames that were sent or received. To configure the
802.1X feature, see the 802.1X Properties page.
To view the EAP Statistics and/or set the refresh rate:
STEP 1 Click Status and Statistics > 802.1x EAP.
STEP 2 Select the Interface that is polled for statistics.
STEP 3 Select the time period (Refresh Rate) that passes before the EAP statistics are
refreshed.
The values are displayed for the selected interface.
• EAPOL Frames Received—Valid EAPOL frames received on the port.
• EAPOL Frames Transmitted—Valid EAPOL frames transmitted by the port.
• EAPOL Start Frames Received—EAPOL Start frames received on the port.
• EAPOL Logoff Frames Received—EAPOL Logoff frames received on the
port.
• EAP Response/ID Frames Received—EAP Resp/ID frames received on the
port.
• EAP Response Frames Received—EAP Response frames received by the
port (other than Resp/ID frames).
• EAP Request/ID Frames Transmitted—EAP Req/ID frames transmitted by
the port.
• EAP Request Frames Transmitted—EAP Request frames transmitted by
the port.

Cisco SG500-28 Specifications

General

Ports	28
Port Type	Gigabit Ethernet
Layer	Layer 3
Switching Capacity	56 Gbps
PoE Support	No
Form Factor	Rack-mountable
RAM	256 MB
Flash Memory	32 MB
Power Supply	Internal
Jumbo Frame Support	9KB
VLAN Support	Yes
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity	10% to 90% non-condensing
Dimensions	17.3 x 10.2 x 1.7 in (440 x 260 x 44 mm)
MAC Address Table Size	16, 000 entries
