Cisco SG500-28 Administration Guide

IP Configuration: RIPv2
Configuring RIP
Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3 352
18
Creating an Access List
To set the global configuration of an access list.
STEP 1 Click IP Configuration > Access List > Access List Settings.
STEP 2 To add a new Access List, click Add to open the Add Access List page and enter
the following fields:
• Name—Define a name for the access list.
• Source IPv4 Address—Enter the source IPv4 address. The following
options are available:
- Any—All IP addresses are included.
- User Defined—Enter an IP address.
• Source IPv4 Mask—Enter the source IPv4 address mask type and value.
The following options are available:
- Network Mask—Enter the network mask.
- Prefix Length—Enter the prefix length.
• Action—Select an action for the access list. The following options are
available:
- Permit—Permit entry of packets from the IP address(es) in the access
list.
- Deny—Reject entry of packets from the IP address(es) in the access list.
Populate an Access List
To populate an access list with IP addresses.
STEP 1 Click IP Configuration > Access List > Source IPv4 Address List.
STEP 2 To modify the parameters of an access list, click Add to open the Edit Access List
page and modify any of the following fields:
• Access List Name—Name of the access list.
• Source IPv4 Address—Source IPv4 address. The following options are
available:

Cisco SG500-28 Specifications

General

Ports	28
Port Type	Gigabit Ethernet
Layer	Layer 3
Switching Capacity	56 Gbps
PoE Support	No
Form Factor	Rack-mountable
RAM	256 MB
Flash Memory	32 MB
Power Supply	Internal
Jumbo Frame Support	9KB
VLAN Support	Yes
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity	10% to 90% non-condensing
Dimensions	17.3 x 10.2 x 1.7 in (440 x 260 x 44 mm)
MAC Address Table Size	16, 000 entries
